BOPS WINDOWS ENVELOPE FILM (Biaxially oriented polystyrene film)
BOPS windows envelope film (environmental protection type)
1. Spec. sizes : BOPS window envelop film (Biaxially oriented polystyrene film)
Density: 1.02-1.05(g/CM3) Color: Clear/ transparent, Thickness: 22.5 g/m2 (25 Microns), 27 g/m2 (30 Microns), 29 g/m2 ( 32 Microns), 35 g/m2 ( 39 Microns), Width : 100,115,120,125,130,135,140,150... MM. Length : 2000-4000M .
Specifications: Density: 1.05 (g/cm3) Color: Transparent Thickness: 20-50 micron Width :90-500 MM Length: 3000-4000 M Production: 10,000 tons per year. Packing: rolls with cardboard boxes.
Features: high gloss (transparent window film 116; the extinction window film 57.9), haze is small (transparent window film is 0.7; the extinction window ≥ 2600 MPa), the tensile strength MD ≥ 50MpaTD ≥ 70Mpa. Controllable optical properties of the haze transparent window film ≤ 3 extinction window film ≤ The the 1825 gloss transparent window film ≥ 100 extinction window film 5565. The modulus of elasticity MD ≥ 2600MpaTD ≥
Uses: 1) courier envelope window film or gift packaging box with window film. A lot of business letters need to open the window design, the various mailing tariff notification, such as: telecommunications, banks, government agencies, etc.. And the original cassette packaging steering fenestration packaging. The envelope window packaging and all kinds of gifts fenestration packaging business needs, BOPS window film came into being and continue to grow.
Is the most suitable use for the envelope window film thin, a very perfect read rates, can improve efficiency, thereby creating economic benefits. Whether it is an envelope manufacturer, bulk mail, the mail sorting business, postal operators, OPS film can bring you better work efficiency and economic benefits.
2. Feature: - Has a very good anti-static ability. - The smoothness of a good film, the production process in an envelope will rarely produce a result of thin film and mechanical standstill. - Film slitting good, with high-intensity endurance, meanwhile horizontally easily torn, very suitable for the production of high-speed operation of the envelope. - Low-cost, in China and Japan are using the standard 25um thickness, and other companies produced BOPS Materials 27um, 29um, compared the cost of a cheap film envelopes 8% ~ 16%.
3. Technology data / Test report :
PROPERTIES 性能 |
UNIT 单位 |
RESULT 指标 |
TEST STANDARD 测定方法 |
AVERAGE GAUGE 平均厚度 |
MICRON μm |
25.07 |
- |
THICKNESS TOLERRANCE(MAX) 厚度偏差 |
% |
±5 |
|
HAZE 雾度 |
% |
1.7 |
ASTM D-1003 |
GLOSS 45° 光泽度 |
% |
120 |
ASTM D-2457 |
TENSILE STRENGTH 抗拉强度 |
MPa |
MD |
27.4 |
JIS K7127 |
MPa |
TD |
48.4 |
JIS K7127 |
ELONGATION AT BREAK 断裂伸长率 |
% |
MD |
113.4 |
JIS K7127 |
% |
TD |
40.26 |
JIS K7127 |
MODULUS OF ELASTICITY 弹性模量 |
Bitmap
|
MD |
1311 |
JIS K7127 |
TD |
1404 |
JIS K7127 |
COF 摩擦系数 |
AA |
AB |
BB |
ASTM D-1894 |
0.508 |
0.520 |
0.455 |
|
